EZ-TRAC™

Surveys in all directions

Robust & reliable

Immediately indicate the quality of azimuth

Dimensions

Outer Diameter

35mm


Length

1,030mm


Weight

4.7kg

Azimuth (direction)
Range

0 to 360º

Accuracy

± 0.35º

Dip (inclination)

± 90º from horizontal

± 0.25º

Gravity roll (rotation/toolface)

0º to 360º

± 0.25º

Magnetic roll (rotation/toolface)

0º to 360º

± 0.35º

Tool magnetic field

0 to 100,000 nT

± 50 nT

Magnetic dip

± 90º from horizontal

± 0.25º

Depth rating

Depth rating

5,000m vertical in fresh water

Operating environment

Full accuracy (calibration range)

0ºC to 60ºC (32ºF to 140ºF)


Operating

-30ºC to 85ºC (-22ºF to 185ºF)


Storage

-45ºC to 85ºC (-49ºF to 185ºF)

Battery
Approximate battery life for downhole instrument:

Infrequent use

4 years


Normal use

2 years


Heavy use

1 year

Non-rechargeable lithium battery pack
Control multiple IMDEX survey tools through one app.
Less wire, less charges, less equipment


Using one tablet and interface with multiple tools at the same time reduces hardware costs (including tablets, and chargers) while increasing functionality. You can now monitor everything from the one app.

Boost productivity


IMDEX SURVEY-IQâ„¢ has crossed the threshold in saving hours for drilling operations by increasing productivity up to four times compared to using conventional apps.



Multi tool, multi stream, real-time information


IMDEX SURVEY-IQâ„¢ allows efficient and simultaneous quality assured survey and gamma logging that can be completed by one member of the drill crew. Survey results are immediately available for approval via the cloud-based service IMDEXHUB-IQâ„¢. As well as further analysis in ioGASâ„¢ or 3D visualisation software such as Seequent Central

Time stamped drillers run sheet


With paperless run sheets, the driller or supervisor has the ability to work out how many meters per shift, when the drilling happened, and even if there were stops or delays.
